Cones Machine


Ice Cream Biscuit Cones Processing Line Model M

  • Material: flour,egg,water
  • Capacity: 3600-7000pcs/h
  • Loading Port: Qingdao Port

Description:

Biscuit cone processing line Model M: There are two pieces of wafers on each baking plate,It can make the cones from 60mm-110mm.

Thank you for visiting our site! Please feel free to submit this form with any questions or comments. We will answer your message within 24 hours.
flour,egg,water3600-7000pcs/hQingdao Port
 Features

Ice cream biscuit cones processing line Model M: There are two pieces of wafers on each baking plate,It can make the cones from 60mm-110mm.

And we can design and make other models and specifications according to the different requirements from the client.
The same ice cream cones machine can make different products within round biscuit,sugar rolled cone,egg roll with changing the different forming devices.
The waffle baking oven is constructed with robust steel frame with a chain path and a continous line chain that carries the tong carriages and baking plates.
The conveyor of the oven with baking plates moves on running wheels. We have developed low maintainance bearings and bushes as running wheels and locking rollers.

Video:
 Technical Data
Model Machine Measurement Drive Motor Rolling System Motor Air Blower Gas Consumption
(kg/h)
Producing Capacity
(pc/h)
Total Weight
(kg)
LG61*2-24M 8.86*1.9*1.65 380V,1.5KW 380V,0.37KW 380V,1.5KW 9-11 6600-7000 5000
LG53*2-24M 7.9*1.9*1.65 380V,1.5KW 380V,0.37KW 380V,1.5KW 7-9 6600-7000 4600
LG45*2-16M 7.1*1.9*1.65 380V,1.5KW 380V,0.37KW 380V,1.5KW 6-7 4600-5000 4000
LG37*2-16M 6.1*1.9*1.65 380V,1.5KW 380V,0.37KW 380V,1.5KW 5-6 3600-4000 3600
