Cones Machine


Automatic Waffle Cone Making Machine Line

  • Material: flour,egg,sugar etc
  • Capacity: 3500-8000pcs/h,can be customized
  • WhatsApp: 0086-18538123076

Description:

Automatic Waffle Sugar Cone Machine is suitable for industrial ice cream cones baking and rolling, and the sizes of the final ice cream cones can be various.Email sales@longerinc.com

flour,egg,sugar etc3500-8000pcs/h,can be customizedQingdao Port
 Features
This automatic ice cream rolled sugar cones production line is mainly used to make crispy flat sugar cones. The height and diameter of the finished ice cream cones can be customized.
LONGER Machinery produces many kinds of ice cream cone machine,such as semi-automatic cone machine,automatic cone machines and ice cream cone production line.
LONGER Machinery also have the wafer ice cream cone machines for different popular shapes in china and all over the worlds.


1.The ice cream cones production line is suitable for making flat sugar cones with size length less than 120mm. The cones' degree, weight, thickness and pattern spacing can be customized according to customer demand.
2.The sugar cones machine is driven by the 3 phases power and backing oven is heating with gas (natural gas or liquid gas), electric  ignition, oven temperature electronic display. The producing ability is very high and it is all automatic from spraying the batter, baking, forming, falling off from molds, conveying products, stacking and counting.
3. The sugar cones production line is consisted of 280*240mm baking plates, and the plates material is high-qualified ductile cast iron, each plate can make two cone sheets.




LONGER Machinery also offer Semi-automatic Waffle Cones Machine



 Technical Data
Model LG37×2-16A LG45×2-16A LG53×2-16A LG61×2-24A LG75×2-30A
Drive motor 380V 1.5KW 380V 1.5KW 380V 2.2KW 380V 2.2KW 380V 2.2KW
Rolling system motor 380V 0.37KW 380V 0.37KW 380V 0.37KW 380V 0.37KW 380V 0.37KW
Air blower 380V 1.1KW 380V 1.1KW 380V 1.6KW 380V 2.2KW 380V 2.2KW
Gas consumption
(kg/h)
5-7 6-7 8-12 9-11 11-13
Producing capacity
(pcs/h)
3500-4000 4500-5000 5500-6000 6500-7000 7500-8000
Food-grade conveyor 5000*460*500 5000*460*500 5000*460*500 5000*460*500 5000*460*500
Automatic counter 3000*460*400 3000*460*400 3000*460*400 3000*460*400 3000*460*400
Mixer 190L 190L 190L 190L 190L
Machine measurement
(m)
7.05×1.90×1.73 8.52×1.90×1.73 9.80×1.90×1.73 11.32×1.90×1.73 13.52×1.90×1.73
Total weight 4200kgs 4800kgs 5300kgs 5800kgs 7200kgs
