Chikki Plant
Sesame Brittle Bar Making Machine|Sesame Candy Processing Line
- Material: sesame,peanut,cashew nut, etc
- Capacity: 100-500kg/h,can be customized
- Loading Port: Qingdao Port
Description:
The sesame brittle bar production line consists of sesame roaster machine, sugar cooking pot, control mixer forming machine and packaging machine,with capacity 100-500kg/h
Features
The sesame brittle bar production line consists of sesame roaster machine, sugar cooking pot, control mixer forming machine and packaging machine. Sesame candy machines are made of high quality stainless steel, it can be used to make caramel treats/sachima, peanut/sesame brittle, nuts cakes and many different products. This roaster machine has a simple structure and it is very easy to operate. This machine uses the round reducer as power, and the chains drive the turning cage to roast the materials. Adopting the way of infrared heating to roast the materials by heat radiation from the pipe heaters. You can choose machine whole made of 304 stainless and machine outer made of carbon steel and inner turning cage made of 304 stainless steel.
The forming machine is first choice for sesame crisp flake slice forming machine by using two- press and one cut for sesame crisp flake with features of stable performance, reasonable structure, being easy to operate and easy to maintain. Automatic packing machine is mainly used for biscuits, bread, moon cake, candy, eggs, sweet potato cakes, caramel treats, daily necessities, hardware parts, cartons or pallets and other solid objects with the packaging rules.
Advantages of peanut candy making machine:
1. High quality, machine is made of stainless steel 304, conform food safety requirement.
2. Working process is simple, only consist of mixing machine, molding and cutting machine. Of course if need other machine, like sugar pot, pillow packing machine, we can supply.
3. Mixing machine is nonstick barrel wall, stir uniform, non-stick pot
4. Machines working is automatic. Between molding machine and cutting machine, there will be conveyor, making processing more easier, easy to operate.
5. Products size can be adjustable. Our machine can customize tray groove and cutter distance to control product size.
6. Automatic control reciprocation, flattened uniformly smooth. Automatic dicer, one time molding, product size, weight keep same.
7. Elegant and beautiful performance, compact structure and durable.
Technical Data
| No. | Equipment Name |
Output |
Power (kw) |
Dimension (mm) |
Quantity |
| 1 | Sesame Automatic Roaster | 200kg/h | 24 | 2700*1260*1550 | 1 |
| 2 | Automatic Sugar Cooking Pot | 100L | 15 | 1200*1000*800 | 1 |
| 3 | Temperature Control Mixer | 3-8kg/time | 4.1 | 680*500*800 | 1 |
| 4 | Automatic Forming Machine | 200-300kg/h | 2.2 | 3800*1000*1600 | 1 |
| 5 | Automatic Packing Machine | 50-250bag/min | 2.5 | 4000*950*1450 | 1 |
